first commit

kivy_venv/share/kivy-examples/canvas/bezier.py

@@ -0,0 +1,105 @@
+'''
+Bezier Example
+==============
+
+This example shows a closed Bezier curve computed from a polygon. You
+should see a purple polygon, a red bezier curve computed from the polygon,
+and two sliders. You can drag points on the polygon to recompute the curve.
+The two sliders control the dash length of the dashed lines making up the two
+shapes.
+
+'''
+from kivy.app import App
+from kivy.uix.floatlayout import FloatLayout
+from kivy.uix.slider import Slider
+from kivy.graphics import Color, Bezier, Line
+
+
+class BezierTest(FloatLayout):
+
+    def __init__(self, points=[], loop=False, *args, **kwargs):
+        super(BezierTest, self).__init__(*args, **kwargs)
+        self.d = 10  # pixel tolerance when clicking on a point
+        self.points = points
+        self.loop = loop
+        self.current_point = None  # index of point being dragged
+
+        with self.canvas:
+            Color(1.0, 0.0, 0.0)
+
+            self.bezier = Bezier(
+                    points=self.points,
+                    segments=150,
+                    loop=self.loop,
+                    dash_length=100,
+                    dash_offset=10)
+
+            Color(1.0, 0.0, 1.0)
+            self.line = Line(
+                    points=self.points + self.points[:2],
+                    dash_offset=10,
+                    dash_length=100)
+
+        s = Slider(y=0, pos_hint={'x': .3}, size_hint=(.7, None), height=50)
+        s.bind(value=self._set_bezier_dash_offset)
+        self.add_widget(s)
+
+        s = Slider(y=50, pos_hint={'x': .3}, size_hint=(.7, None), height=50)
+        s.bind(value=self._set_line_dash_offset)
+        self.add_widget(s)
+
+    def _set_bezier_dash_offset(self, instance, value):
+        # effect to reduce length while increase offset
+        self.bezier.dash_length = 100 - value
+        self.bezier.dash_offset = value
+
+    def _set_line_dash_offset(self, instance, value):
+        # effect to reduce length while increase offset
+        self.line.dash_length = 100 - value
+        self.line.dash_offset = value
+
+    def on_touch_down(self, touch):
+        if self.collide_point(touch.pos[0], touch.pos[1]):
+            for i, p in enumerate(list(zip(self.points[::2],
+                                           self.points[1::2]))):
+                if (abs(touch.pos[0] - self.pos[0] - p[0]) < self.d and
+                        abs(touch.pos[1] - self.pos[1] - p[1]) < self.d):
+                    self.current_point = i + 1
+                    return True
+            return super(BezierTest, self).on_touch_down(touch)
+
+    def on_touch_up(self, touch):
+        if self.collide_point(touch.pos[0], touch.pos[1]):
+            if self.current_point:
+                self.current_point = None
+                return True
+            return super(BezierTest, self).on_touch_up(touch)
+
+    def on_touch_move(self, touch):
+        if self.collide_point(touch.pos[0], touch.pos[1]):
+            c = self.current_point
+            if c:
+                self.points[(c - 1) * 2] = touch.pos[0] - self.pos[0]
+                self.points[(c - 1) * 2 + 1] = touch.pos[1] - self.pos[1]
+                self.bezier.points = self.points
+                self.line.points = self.points + self.points[:2]
+                return True
+            return super(BezierTest, self).on_touch_move(touch)
+
+
+class Main(App):
+
+    def build(self):
+        from math import cos, sin, radians
+        x = y = 150
+        z = 100
+        # Pacman !
+        points = [x, y]
+        for i in range(45, 360, 45):
+            i = radians(i)
+            points.extend([x + cos(i) * z, y + sin(i) * z])
+        return BezierTest(points=points, loop=True)
+
+
+if __name__ == '__main__':
+    Main().run()

kivy_venv/share/kivy-examples/canvas/canvas_stress.py

@@ -0,0 +1,72 @@
+'''
+Canvas stress
+=============
+
+This example tests the performance of our Graphics engine by drawing large
+numbers of small squares. You should see a black canvas with buttons and a
+label at the bottom. Pressing the buttons adds small colored squares to the
+canvas.
+
+'''
+
+from kivy.uix.button import Button
+from kivy.uix.widget import Widget
+from kivy.uix.label import Label
+from kivy.uix.boxlayout import BoxLayout
+from kivy.app import App
+from kivy.graphics import Color, Rectangle
+from random import random as r
+from functools import partial
+
+
+class StressCanvasApp(App):
+
+    def add_rects(self, label, wid, count, *largs):
+        label.text = str(int(label.text) + count)
+        with wid.canvas:
+            for x in range(count):
+                Color(r(), 1, 1, mode='hsv')
+                Rectangle(pos=(r() * wid.width + wid.x,
+                               r() * wid.height + wid.y), size=(20, 20))
+
+    def double_rects(self, label, wid, *largs):
+        count = int(label.text)
+        self.add_rects(label, wid, count, *largs)
+
+    def reset_rects(self, label, wid, *largs):
+        label.text = '0'
+        wid.canvas.clear()
+
+    def build(self):
+        wid = Widget()
+
+        label = Label(text='0')
+
+        btn_add100 = Button(text='+ 100 rects',
+                            on_press=partial(self.add_rects, label, wid, 100))
+
+        btn_add500 = Button(text='+ 500 rects',
+                            on_press=partial(self.add_rects, label, wid, 500))
+
+        btn_double = Button(text='x 2',
+                            on_press=partial(self.double_rects, label, wid))
+
+        btn_reset = Button(text='Reset',
+                           on_press=partial(self.reset_rects, label, wid))
+
+        layout = BoxLayout(size_hint=(1, None), height=50)
+        layout.add_widget(btn_add100)
+        layout.add_widget(btn_add500)
+        layout.add_widget(btn_double)
+        layout.add_widget(btn_reset)
+        layout.add_widget(label)
+
+        root = BoxLayout(orientation='vertical')
+        root.add_widget(wid)
+        root.add_widget(layout)
+
+        return root
+
+
+if __name__ == '__main__':
+    StressCanvasApp().run()

kivy_venv/share/kivy-examples/canvas/circle.py

@@ -0,0 +1,84 @@
+'''
+Circle Example
+==============
+
+This example exercises circle (ellipse) drawing. You should see sliders at the
+top of the screen with the Kivy logo below it. The sliders control the
+angle start and stop and the height and width scales. There is a button
+to reset the sliders. The logo used for the circle's background image is
+from the kivy/data directory. The entire example is coded in the
+kv language description.
+'''
+
+from kivy.app import App
+from kivy.lang import Builder
+
+kv = '''
+BoxLayout:
+    orientation: 'vertical'
+    BoxLayout:
+        size_hint_y: None
+        height: sp(100)
+        BoxLayout:
+            orientation: 'vertical'
+            Slider:
+                id: e1
+                min: -360.
+                max: 360.
+            Label:
+                text: 'angle_start = {}'.format(e1.value)
+        BoxLayout:
+            orientation: 'vertical'
+            Slider:
+                id: e2
+                min: -360.
+                max: 360.
+                value: 360
+            Label:
+                text: 'angle_end = {}'.format(e2.value)
+
+    BoxLayout:
+        size_hint_y: None
+        height: sp(100)
+        BoxLayout:
+            orientation: 'vertical'
+            Slider:
+                id: wm
+                min: 0
+                max: 2
+                value: 1
+            Label:
+                text: 'Width mult. = {}'.format(wm.value)
+        BoxLayout:
+            orientation: 'vertical'
+            Slider:
+                id: hm
+                min: 0
+                max: 2
+                value: 1
+            Label:
+                text: 'Height mult. = {}'.format(hm.value)
+        Button:
+            text: 'Reset ratios'
+            on_press: wm.value = 1; hm.value = 1
+
+    FloatLayout:
+        canvas:
+            Color:
+                rgb: 1, 1, 1
+            Ellipse:
+                pos: 100, 100
+                size: 200 * wm.value, 201 * hm.value
+                source: 'data/logo/kivy-icon-512.png'
+                angle_start: e1.value
+                angle_end: e2.value
+
+'''
+
+
+class CircleApp(App):
+    def build(self):
+        return Builder.load_string(kv)
+
+
+CircleApp().run()

kivy_venv/share/kivy-examples/canvas/fbo_canvas.py

@@ -0,0 +1,91 @@
+'''
+FBO Canvas
+==========
+
+This demonstrates a layout using an FBO (Frame Buffer Off-screen)
+instead of a plain canvas. You should see a black canvas with a
+button labelled 'FBO' in the bottom left corner. Clicking it
+animates the button moving right to left.
+'''
+
+__all__ = ('FboFloatLayout', )
+
+from kivy.graphics import Color, Rectangle, Canvas, ClearBuffers, ClearColor
+from kivy.graphics.fbo import Fbo
+from kivy.uix.floatlayout import FloatLayout
+from kivy.properties import ObjectProperty, NumericProperty
+from kivy.app import App
+from kivy.core.window import Window
+from kivy.animation import Animation
+from kivy.factory import Factory
+
+
+class FboFloatLayout(FloatLayout):
+
+    texture = ObjectProperty(None, allownone=True)
+
+    alpha = NumericProperty(1)
+
+    def __init__(self, **kwargs):
+        self.canvas = Canvas()
+        with self.canvas:
+            self.fbo = Fbo(size=self.size)
+            self.fbo_color = Color(1, 1, 1, 1)
+            self.fbo_rect = Rectangle()
+
+        with self.fbo:
+            ClearColor(0, 0, 0, 0)
+            ClearBuffers()
+
+        # wait that all the instructions are in the canvas to set texture
+        self.texture = self.fbo.texture
+        super(FboFloatLayout, self).__init__(**kwargs)
+
+    def add_widget(self, *args, **kwargs):
+        # trick to attach graphics instruction to fbo instead of canvas
+        canvas = self.canvas
+        self.canvas = self.fbo
+        ret = super(FboFloatLayout, self).add_widget(*args, **kwargs)
+        self.canvas = canvas
+        return ret
+
+    def remove_widget(self, *args, **kwargs):
+        canvas = self.canvas
+        self.canvas = self.fbo
+        super(FboFloatLayout, self).remove_widget(*args, **kwargs)
+        self.canvas = canvas
+
+    def on_size(self, instance, value):
+        self.fbo.size = value
+        self.texture = self.fbo.texture
+        self.fbo_rect.size = value
+
+    def on_pos(self, instance, value):
+        self.fbo_rect.pos = value
+
+    def on_texture(self, instance, value):
+        self.fbo_rect.texture = value
+
+    def on_alpha(self, instance, value):
+        self.fbo_color.rgba = (1, 1, 1, value)
+
+
+class ScreenLayerApp(App):
+    def build(self):
+
+        f = FboFloatLayout()
+        b = Factory.Button(text="FBO", size_hint=(None, None))
+        f.add_widget(b)
+
+        def anim_btn(*args):
+            if b.pos[0] == 0:
+                Animation(x=f.width - b.width).start(b)
+            else:
+                Animation(x=0).start(b)
+        b.bind(on_press=anim_btn)
+
+        return f
+
+
+if __name__ == "__main__":
+    ScreenLayerApp().run()

kivy_venv/share/kivy-examples/canvas/lines.py

@@ -0,0 +1,296 @@
+'''
+Line (SmoothLine) Experiment
+============================
+
+This demonstrates the experimental and unfinished SmoothLine feature
+for fast line drawing. You should see a multi-segment
+path at the top of the screen, and sliders and buttons along the bottom.
+You can click to add new points to the segment, change the transparency
+and width of the line, or hit 'Animate' to see a set of sine and cosine
+animations. The Cap and Joint buttons don't work: SmoothLine has not
+implemented these features yet.
+'''
+
+from kivy.app import App
+from kivy.properties import OptionProperty, NumericProperty, ListProperty, \
+        BooleanProperty
+from kivy.uix.floatlayout import FloatLayout
+from kivy.lang import Builder
+from kivy.clock import Clock
+from math import cos, sin
+
+Builder.load_string('''
+<LinePlayground>:
+    canvas:
+        Color:
+            rgba: .4, .4, 1, root.alpha
+        Line:
+            points: self.points
+            joint: self.joint
+            cap: self.cap
+            width: self.linewidth
+            close: self.close
+            dash_length: self.dash_length
+            dash_offset: self.dash_offset
+            dashes: self.dashes
+        Color:
+            rgba: .8, .8, .8, root.alpha_controlline
+        Line:
+            points: self.points
+            close: self.close
+            dash_length: self.dash_length
+            dash_offset: self.dash_offset
+            dashes: self.dashes
+        Color:
+            rgba: 1, .4, .4, root.alpha
+        Line:
+            points: self.points2
+            joint: self.joint
+            cap: self.cap
+            width: self.linewidth
+            close: self.close
+            dash_length: self.dash_length
+            dash_offset: self.dash_offset
+            dashes: self.dashes
+
+    GridLayout:
+        cols: 2
+        size_hint: 1, None
+        height: 44 * 5
+
+        GridLayout:
+            cols: 2
+
+            Label:
+                text: 'Alpha'
+            Slider:
+                value: root.alpha
+                on_value: root.alpha = float(args[1])
+                min: 0.
+                max: 1.
+            Label:
+                text: 'Alpha Control Line'
+            Slider:
+                value: root.alpha_controlline
+                on_value: root.alpha_controlline = float(args[1])
+                min: 0.
+                max: 1.
+            Label:
+                text: 'Width'
+            Slider:
+                value: root.linewidth
+                on_value: root.linewidth = args[1]
+                min: 1
+                max: 40
+            Label:
+                text: 'Cap'
+            GridLayout:
+                rows: 1
+                ToggleButton:
+                    group: 'cap'
+                    text: 'none'
+                    on_press: root.cap = self.text
+                ToggleButton:
+                    group: 'cap'
+                    text: 'round'
+                    on_press: root.cap = self.text
+                ToggleButton:
+                    group: 'cap'
+                    text: 'square'
+                    on_press: root.cap = self.text
+            Label:
+                text: 'Joint'
+            GridLayout:
+                rows: 1
+                ToggleButton:
+                    group: 'joint'
+                    text: 'none'
+                    on_press: root.joint = self.text
+                ToggleButton:
+                    group: 'joint'
+                    text: 'round'
+                    on_press: root.joint = self.text
+                ToggleButton:
+                    group: 'joint'
+                    text: 'miter'
+                    on_press: root.joint = self.text
+                ToggleButton:
+                    group: 'joint'
+                    text: 'bevel'
+                    on_press: root.joint = self.text
+
+            Label:
+                text: 'Close'
+            ToggleButton:
+                text: 'Close line'
+                on_press: root.close = self.state == 'down'
+
+            Label:
+                text: 'Dashes'
+            GridLayout:
+                rows: 1
+                ToggleButton:
+                    group: 'dashes'
+                    text: 'none'
+                    state: 'down'
+                    allow_no_selection: False
+                    size_hint_x: None
+                    width: self.texture_size[0]
+                    padding_x: '5dp'
+                    on_state:
+                        if self.state == 'down': root.dashes = []
+                        if self.state == 'down': root.dash_length = 1
+                        if self.state == 'down': root.dash_offset = 0
+                ToggleButton:
+                    id: constant
+                    group: 'dashes'
+                    text: 'Constant: '
+                    allow_no_selection: False
+                    size_hint_x: None
+                    width: self.texture_size[0]
+                    padding_x: '5dp'
+                    on_state:
+                        if self.state == 'down': root.dashes = []
+                        if self.state == 'down': root.dash_length = \
+                            int(dash_len.text or 1)
+                        if self.state == 'down': root.dash_offset = \
+                            int(dash_offset.text or 0)
+                Label:
+                    text: 'len'
+                    size_hint_x: None
+                    width: self.texture_size[0]
+                    padding_x: '5dp'
+                TextInput:
+                    id: dash_len
+                    size_hint_x: None
+                    width: '30dp'
+                    input_filter: 'int'
+                    multiline: False
+                    text: '1'
+                    on_text: if constant.state == 'down': \
+                        root.dash_length = int(self.text or 1)
+                Label:
+                    text: 'offset'
+                    size_hint_x: None
+                    width: self.texture_size[0]
+                    padding_x: '5dp'
+                TextInput:
+                    id: dash_offset
+                    size_hint_x: None
+                    width: '30dp'
+                    input_filter: 'int'
+                    multiline: False
+                    text: '0'
+                    on_text: if constant.state == 'down': \
+                        root.dash_offset = int(self.text or 0)
+                ToggleButton:
+                    id: dash_list
+                    group: 'dashes'
+                    text: 'List: '
+                    allow_no_selection: False
+                    size_hint_x: None
+                    width: self.texture_size[0]
+                    padding_x: '5dp'
+                    on_state:
+                        if self.state == 'down': root.dashes = list(map(lambda\
+                            x: int(x or 0), dash_list_in.text.split(',')))
+                        if self.state == 'down': root.dash_length = 1
+                        if self.state == 'down': root.dash_offset = 0
+                TextInput:
+                    id: dash_list_in
+                    size_hint_x: None
+                    width: '180dp'
+                    multiline: False
+                    text: '4,3,10,15'
+                    on_text: if dash_list.state == 'down': root.dashes = \
+                        list(map(lambda x: int(x or 0), self.text.split(',')))
+
+        AnchorLayout:
+            GridLayout:
+                cols: 1
+                size_hint: None, None
+                size: self.minimum_size
+                ToggleButton:
+                    size_hint: None, None
+                    size: 100, 44
+                    text: 'Animate'
+                    on_state: root.animate(self.state == 'down')
+                Button:
+                    size_hint: None, None
+                    size: 100, 44
+                    text: 'Clear'
+                    on_press: root.points = root.points2 = []
+
+''')
+
+
+class LinePlayground(FloatLayout):
+
+    alpha_controlline = NumericProperty(1.0)
+    alpha = NumericProperty(0.5)
+    close = BooleanProperty(False)
+    points = ListProperty([(500, 500),
+                          [300, 300, 500, 300],
+                          [500, 400, 600, 400]])
+    points2 = ListProperty([])
+    joint = OptionProperty('none', options=('round', 'miter', 'bevel', 'none'))
+    cap = OptionProperty('none', options=('round', 'square', 'none'))
+    linewidth = NumericProperty(10.0)
+    dt = NumericProperty(0)
+    dash_length = NumericProperty(1)
+    dash_offset = NumericProperty(0)
+    dashes = ListProperty([])
+
+    _update_points_animation_ev = None
+
+    def on_touch_down(self, touch):
+        if super(LinePlayground, self).on_touch_down(touch):
+            return True
+        touch.grab(self)
+        self.points.append(touch.pos)
+        return True
+
+    def on_touch_move(self, touch):
+        if touch.grab_current is self:
+            self.points[-1] = touch.pos
+            return True
+        return super(LinePlayground, self).on_touch_move(touch)
+
+    def on_touch_up(self, touch):
+        if touch.grab_current is self:
+            touch.ungrab(self)
+            return True
+        return super(LinePlayground, self).on_touch_up(touch)
+
+    def animate(self, do_animation):
+        if do_animation:
+            self._update_points_animation_ev = Clock.schedule_interval(
+                self.update_points_animation, 0)
+        elif self._update_points_animation_ev is not None:
+            self._update_points_animation_ev.cancel()
+
+    def update_points_animation(self, dt):
+        cy = self.height * 0.6
+        cx = self.width * 0.1
+        w = self.width * 0.8
+        step = 20
+        points = []
+        points2 = []
+        self.dt += dt
+        for i in range(int(w / step)):
+            x = i * step
+            points.append(cx + x)
+            points.append(cy + cos(x / w * 8. + self.dt) * self.height * 0.2)
+            points2.append(cx + x)
+            points2.append(cy + sin(x / w * 8. + self.dt) * self.height * 0.2)
+        self.points = points
+        self.points2 = points2
+
+
+class TestLineApp(App):
+    def build(self):
+        return LinePlayground()
+
+
+if __name__ == '__main__':
+    TestLineApp().run()

kivy_venv/share/kivy-examples/canvas/lines_extended.py

@@ -0,0 +1,183 @@
+'''
+Lines Extended Demo
+===================
+
+This demonstrates how to use the extended line drawing routines such
+as circles, ellipses, and rectangles. You should see a static image of
+labelled shapes on the screen.
+'''
+
+from kivy.app import App
+from kivy.uix.gridlayout import GridLayout
+from kivy.uix.widget import Widget
+from kivy.lang import Builder
+
+Builder.load_string('''
+<LineEllipse1>:
+    canvas:
+        Color:
+            rgba: 1, .1, .1, .9
+        Line:
+            width: 2.
+            ellipse: (self.x, self.y, self.width, self.height)
+    Label:
+        center: root.center
+        text: 'Ellipse'
+
+<LineEllipse2>:
+    canvas:
+        Color:
+            rgba: 1, .1, .1, .9
+        Line:
+            width: 2.
+            ellipse: (self.x, self.y, self.width, self.height, 90, 180)
+    Label:
+        center: root.center
+        text: 'Ellipse from 90 to 180'
+
+# fun result with low segments!
+<LineEllipse3>:
+    canvas:
+        Color:
+            rgba: 1, .1, .1, .9
+        Line:
+            width: 2.
+            ellipse: (self.x, self.y, self.width, self.height, 90, 720, 10)
+    Label:
+        center: root.center
+        text: 'Ellipse from 90 to 720\\n10 segments'
+        halign: 'center'
+
+<LineCircle1>:
+    canvas:
+        Color:
+            rgba: .1, 1, .1, .9
+        Line:
+            width: 2.
+            circle:
+                (self.center_x, self.center_y, min(self.width, self.height)
+                / 2)
+    Label:
+        center: root.center
+        text: 'Circle'
+
+<LineCircle2>:
+    canvas:
+        Color:
+            rgba: .1, 1, .1, .9
+        Line:
+            width: 2.
+            circle:
+                (self.center_x, self.center_y, min(self.width, self.height)
+                / 2, 90, 180)
+    Label:
+        center: root.center
+        text: 'Circle from 90 to 180'
+
+<LineCircle3>:
+    canvas:
+        Color:
+            rgba: .1, 1, .1, .9
+        Line:
+            width: 2.
+            circle:
+                (self.center_x, self.center_y, min(self.width, self.height)
+                / 2, 90, 180, 10)
+    Label:
+        center: root.center
+        text: 'Circle from 90 to 180\\n10 segments'
+        halign: 'center'
+
+<LineCircle4>:
+    canvas:
+        Color:
+            rgba: .1, 1, .1, .9
+        Line:
+            width: 2.
+            circle:
+                (self.center_x, self.center_y, min(self.width, self.height)
+                / 2, 0, 360)
+    Label:
+        center: root.center
+        text: 'Circle from 0 to 360'
+        halign: 'center'
+
+<LineRectangle>:
+    canvas:
+        Color:
+            rgba: .1, .1, 1, .9
+        Line:
+            width: 2.
+            rectangle: (self.x, self.y, self.width, self.height)
+    Label:
+        center: root.center
+        text: 'Rectangle'
+
+<LineBezier>:
+    canvas:
+        Color:
+            rgba: .1, .1, 1, .9
+        Line:
+            width: 2.
+            bezier:
+                (self.x, self.y, self.center_x - 40, self.y + 100,
+                self.center_x + 40, self.y - 100, self.right, self.y)
+    Label:
+        center: root.center
+        text: 'Bezier'
+''')
+
+
+class LineEllipse1(Widget):
+    pass
+
+
+class LineEllipse2(Widget):
+    pass
+
+
+class LineEllipse3(Widget):
+    pass
+
+
+class LineCircle1(Widget):
+    pass
+
+
+class LineCircle2(Widget):
+    pass
+
+
+class LineCircle3(Widget):
+    pass
+
+
+class LineCircle4(Widget):
+    pass
+
+
+class LineRectangle(Widget):
+    pass
+
+
+class LineBezier(Widget):
+    pass
+
+
+class LineExtendedApp(App):
+    def build(self):
+        root = GridLayout(cols=2, padding=50, spacing=50)
+        root.add_widget(LineEllipse1())
+        root.add_widget(LineEllipse2())
+        root.add_widget(LineEllipse3())
+        root.add_widget(LineCircle1())
+        root.add_widget(LineCircle2())
+        root.add_widget(LineCircle3())
+        root.add_widget(LineCircle4())
+        root.add_widget(LineRectangle())
+        root.add_widget(LineBezier())
+        return root
+
+
+if __name__ == '__main__':
+    LineExtendedApp().run()

kivy_venv/share/kivy-examples/canvas/mesh.py

@@ -0,0 +1,57 @@
+'''
+Mesh test
+=========
+
+This demonstrates the use of a mesh mode to distort an image. You should see
+a line of buttons across the bottom of a canvas. Pressing them displays
+the mesh, a small circle of points, with different mesh.mode settings.
+'''
+
+from kivy.uix.button import Button
+from kivy.uix.widget import Widget
+from kivy.uix.boxlayout import BoxLayout
+from kivy.app import App
+from kivy.graphics import Mesh
+from functools import partial
+from math import cos, sin, pi
+
+
+class MeshTestApp(App):
+
+    def change_mode(self, mode, *largs):
+        self.mesh.mode = mode
+
+    def build_mesh(self):
+        """ returns a Mesh of a rough circle. """
+        vertices = []
+        indices = []
+        step = 10
+        istep = (pi * 2) / float(step)
+        for i in range(step):
+            x = 300 + cos(istep * i) * 100
+            y = 300 + sin(istep * i) * 100
+            vertices.extend([x, y, 0, 0])
+            indices.append(i)
+        return Mesh(vertices=vertices, indices=indices)
+
+    def build(self):
+        wid = Widget()
+        with wid.canvas:
+            self.mesh = self.build_mesh()
+
+        layout = BoxLayout(size_hint=(1, None), height=50)
+        for mode in ('points', 'line_strip', 'line_loop', 'lines',
+                'triangle_strip', 'triangle_fan'):
+            button = Button(text=mode)
+            button.bind(on_release=partial(self.change_mode, mode))
+            layout.add_widget(button)
+
+        root = BoxLayout(orientation='vertical')
+        root.add_widget(wid)
+        root.add_widget(layout)
+
+        return root
+
+
+if __name__ == '__main__':
+    MeshTestApp().run()

kivy_venv/share/kivy-examples/canvas/mesh_manipulation.py

@@ -0,0 +1,101 @@
+'''
+Mesh Manipulation Example
+=========================
+
+This demonstrates creating a mesh and using it to deform the texture (the
+kivy log). You should see the kivy logo with a five sliders to right.
+The sliders change the mesh points' x and y offsets, radius, and a
+'wobble' deformation's magnitude and speed.
+
+This example is developed in gabriel's blog post at
+http://kivy.org/planet/2014/01/kivy-image-manipulations-with-mesh-and-textures/
+'''
+
+from kivy.app import App
+from kivy.lang import Builder
+from kivy.core.image import Image as CoreImage
+from kivy.properties import ListProperty, ObjectProperty, NumericProperty
+from kivy.clock import Clock
+from kivy.core.window import Window
+from math import sin, cos, pi
+
+
+kv = '''
+BoxLayout:
+    Widget:
+        canvas:
+            Color:
+                rgba: 1, 1, 1, 1
+            Mesh:
+                vertices: app.mesh_points
+                indices: range(len(app.mesh_points) // 4)
+                texture: app.mesh_texture
+                mode: 'triangle_fan'
+    BoxLayout:
+        orientation: 'vertical'
+        size_hint_x: None
+        width: 100
+        Slider:
+            value: app.offset_x
+            on_value: app.offset_x = args[1]
+            min: -1
+            max: 1
+        Slider:
+            value: app.offset_y
+            on_value: app.offset_y = args[1]
+            min: -1
+            max: 1
+        Slider:
+            value: app.radius
+            on_value: app.radius = args[1]
+            min: 10
+            max: 1000
+        Slider:
+            value: app.sin_wobble
+            on_value: app.sin_wobble = args[1]
+            min: -50
+            max: 50
+        Slider:
+            value: app.sin_wobble_speed
+            on_value: app.sin_wobble_speed = args[1]
+            min: 0
+            max: 50
+            step: 1
+'''
+
+
+class MeshBallApp(App):
+    mesh_points = ListProperty([])
+    mesh_texture = ObjectProperty(None)
+    radius = NumericProperty(500)
+    offset_x = NumericProperty(.5)
+    offset_y = NumericProperty(.5)
+    sin_wobble = NumericProperty(0)
+    sin_wobble_speed = NumericProperty(0)
+
+    def build(self):
+        self.mesh_texture = CoreImage('data/logo/kivy-icon-512.png').texture
+        Clock.schedule_interval(self.update_points, 0)
+        return Builder.load_string(kv)
+
+    def update_points(self, *args):
+        """ replace self.mesh_points based on current slider positions.
+        Called continuously by a timer because this only sample code.
+        """
+        points = [Window.width / 2, Window.height / 2, .5, .5]
+        i = 0
+        while i < 2 * pi:
+            i += 0.01 * pi
+            points.extend([
+                Window.width / 2 + cos(i) * (self.radius + self.sin_wobble *
+                                             sin(i * self.sin_wobble_speed)),
+                Window.height / 2 + sin(i) * (self.radius + self.sin_wobble *
+                                              sin(i * self.sin_wobble_speed)),
+                self.offset_x + sin(i),
+                self.offset_y + cos(i)])
+
+        self.mesh_points = points
+
+
+if __name__ == '__main__':
+    MeshBallApp().run()

kivy_venv/share/kivy-examples/canvas/multitexture.py

@@ -0,0 +1,110 @@
+'''
+Multitexture Example
+====================
+
+This example blends two textures: the image mtexture1.png of the letter K
+and the image mtexture2.png of an orange circle. You should see an orange
+K clipped to a circle. It uses a custom shader, written in glsl
+(OpenGL Shading Language), stored in a local string.
+
+Note the image mtexture1.png is a white 'K' on a transparent background, which
+makes it hard to see.
+'''
+
+from kivy.clock import Clock
+from kivy.app import App
+from kivy.uix.widget import Widget
+from kivy.uix.floatlayout import FloatLayout
+from kivy.lang import Builder
+from kivy.core.window import Window
+from kivy.graphics import RenderContext, Color, Rectangle, BindTexture
+
+
+fs_multitexture = '''
+$HEADER$
+
+// New uniform that will receive texture at index 1
+uniform sampler2D texture1;
+
+void main(void) {
+
+    // multiple current color with both texture (0 and 1).
+    // currently, both will use exactly the same texture coordinates.
+    gl_FragColor = frag_color * \
+        texture2D(texture0, tex_coord0) * \
+        texture2D(texture1, tex_coord0);
+}
+'''
+
+
+kv = """
+<MultitextureLayout>:
+
+    Image:
+        source: "mtexture1.png"
+        size_hint: .3,.3
+        id: 1
+        pos: 0,200
+    Image:
+        source: "mtexture2.png"
+        size_hint: .3,.3
+        id: 2
+        pos: 200,200
+
+    MultitextureWidget:
+
+"""
+
+Builder.load_string(kv)
+
+
+class MultitextureWidget(Widget):
+
+    def __init__(self, **kwargs):
+        self.canvas = RenderContext()
+        # setting shader.fs to new source code automatically compiles it.
+        self.canvas.shader.fs = fs_multitexture
+        with self.canvas:
+            Color(1, 1, 1)
+
+            # here, we are binding a custom texture at index 1
+            # this will be used as texture1 in shader.
+            # The filenames are misleading: they do not correspond to the
+            # index here or in the shader.
+            BindTexture(source='mtexture2.png', index=1)
+
+            # create a rectangle with texture (will be at index 0)
+            Rectangle(size=(150, 150), source='mtexture1.png', pos=(500, 200))
+
+        # set the texture1 to use texture index 1
+        self.canvas['texture1'] = 1
+
+        # call the constructor of parent
+        # if they are any graphics objects, they will be added on our new
+        # canvas
+        super(MultitextureWidget, self).__init__(**kwargs)
+
+        # We'll update our glsl variables in a clock
+        Clock.schedule_interval(self.update_glsl, 0)
+
+    def update_glsl(self, *largs):
+        # This is needed for the default vertex shader.
+        self.canvas['projection_mat'] = Window.render_context['projection_mat']
+        self.canvas['modelview_mat'] = Window.render_context['modelview_mat']
+
+
+class MultitextureLayout(FloatLayout):
+
+    def __init__(self, **kwargs):
+        self.size = kwargs['size']
+        super(MultitextureLayout, self).__init__(**kwargs)
+
+
+class MultitextureApp(App):
+
+    def build(self):
+        return MultitextureLayout(size=(600, 600))
+
+
+if __name__ == '__main__':
+    MultitextureApp().run()

kivy_venv/share/kivy-examples/canvas/repeat_texture.py

@@ -0,0 +1,65 @@
+'''
+Repeat Texture on Resize
+========================
+
+This examples repeats the letter 'K' (mtexture1.png) 64 times in a window.
+You should see 8 rows and 8 columns of white K letters, along a label
+showing the current size. As you resize the window, it stays an 8x8.
+This example includes a label with a colored background.
+
+Note the image mtexture1.png is a white 'K' on a transparent background, which
+makes it hard to see.
+'''
+
+from kivy.app import App
+from kivy.uix.image import Image
+from kivy.uix.label import Label
+from kivy.properties import ObjectProperty, ListProperty
+from kivy.lang import Builder
+
+kv = '''
+<LabelOnBackground>:
+    canvas.before:
+        Color:
+            rgb: self.background
+        Rectangle:
+            pos: self.pos
+            size: self.size
+
+FloatLayout:
+    canvas.before:
+        Color:
+            rgb: 1, 1, 1
+        Rectangle:
+            pos: self.pos
+            size: self.size
+            texture: app.texture
+
+    LabelOnBackground:
+        text: '{} (try to resize the window)'.format(root.size)
+        color: (0.4, 1, 1, 1)
+        background: (.3, .3, .3)
+        pos_hint: {'center_x': .5, 'center_y': .5 }
+        size_hint: None, None
+        height: 30
+        width: 250
+
+'''
+
+
+class LabelOnBackground(Label):
+    background = ListProperty((0.2, 0.2, 0.2))
+
+
+class RepeatTexture(App):
+
+    texture = ObjectProperty()
+
+    def build(self):
+        self.texture = Image(source='mtexture1.png').texture
+        self.texture.wrap = 'repeat'
+        self.texture.uvsize = (8, 8)
+        return Builder.load_string(kv)
+
+
+RepeatTexture().run()

kivy_venv/share/kivy-examples/canvas/rotation.py

@@ -0,0 +1,35 @@
+'''
+Rotation Example
+================
+
+This example rotates a button using PushMatrix and PopMatrix. You should see
+a static button with the words 'hello world' rotated at a 45 degree angle.
+'''
+
+
+from kivy.app import App
+from kivy.lang import Builder
+
+kv = '''
+FloatLayout:
+
+    Button:
+        text: 'hello world'
+        size_hint: None, None
+        pos_hint: {'center_x': .5, 'center_y': .5}
+        canvas.before:
+            PushMatrix
+            Rotate:
+                angle: 45
+                origin: self.center
+        canvas.after:
+            PopMatrix
+'''
+
+
+class RotationApp(App):
+    def build(self):
+        return Builder.load_string(kv)
+
+
+RotationApp().run()

kivy_venv/share/kivy-examples/canvas/rounded_rectangle.py

@@ -0,0 +1,153 @@
+# -*- coding: utf-8 -*-
+from kivy.app import App
+from kivy.uix.widget import Widget
+from kivy.graphics import Color, Ellipse, Rectangle, RoundedRectangle
+from kivy.lang import Builder
+
+TEXTURE = 'kiwi.jpg'
+YELLOW = (1, .7, 0)
+ORANGE = (1, .45, 0)
+RED = (1, 0, 0)
+WHITE = (1, 1, 1)
+
+
+class RoundedRectangleWidget(Widget):
+    def prepare(self):
+        with self.canvas:
+            Color(*WHITE)
+
+            # Rectangle of default size 100x100
+            Rectangle(pos=(50, 400))
+
+            # RoundedRectangles of default size 100x100:
+
+            # Textured:
+            RoundedRectangle(
+                pos=(175, 400), radius=[0, 50, 0, 50], source=TEXTURE)
+
+            # Colored:
+            Color(*YELLOW)
+            RoundedRectangle(pos=(300, 400), radius=[0, 50, 0, 50])
+
+            # Textured + Colored
+            # Color(.3,.3,.3, 1)
+            RoundedRectangle(
+                pos=(425, 400), radius=[0, 50, 0, 50], source=TEXTURE)
+
+            # Possible radius arguments:
+            # 1) Same value for each corner
+            Color(*ORANGE)
+
+            # With same radius 20x20
+            RoundedRectangle(pos=(50, 275), radius=[20])
+
+            # With same radius dimensions 20x40
+            RoundedRectangle(pos=(175, 275), radius=[(20, 40)])
+
+            # 2) Different values for each corner
+            Color(*RED)
+
+            # With different radiuses NxN:
+            RoundedRectangle(pos=(300, 275), radius=[10, 20, 30, 40])
+
+            # With different radiuses:
+            RoundedRectangle(
+                pos=(425, 275),
+                radius=[(10, 20), (20, 30), (30, 40), (40, 50)])
+
+            # Default ellipses
+            Color(*WHITE)
+            Ellipse(pos=(50, 150))
+            Ellipse(pos=(175, 150))
+            Ellipse(pos=(300, 150))
+            Ellipse(pos=(425, 150))
+
+            # Radius dimensions can't be bigger than half of the figure side
+            RoundedRectangle(pos=(175, 150), radius=[9000], source=TEXTURE)
+
+            # Segments parameter defines how many segments each corner has.
+            # More segments - more roundness
+            Color(*RED)
+            RoundedRectangle(pos=(300, 150), radius=[9000])
+            RoundedRectangle(pos=(425, 150), radius=[9000], segments=15)
+
+            Color(*ORANGE)
+            RoundedRectangle(pos=(425, 150), radius=[9000], segments=2)
+
+            Color(*YELLOW)
+            RoundedRectangle(pos=(425, 150), radius=[9000], segments=1)
+
+            # Various sizes
+            # You can cut corners by setting segments to 1.
+            # You can set different segment count to corners,
+            # by using a list useful for lowering vertex count
+            # by using small amount on small corners, while using
+            # bigger amount on bigger corners.
+            RoundedRectangle(
+                pos=(50, 25),
+                radius=[40],
+                segments=[1, 1, 10, 10],
+                size=(125, 100))
+
+            # If radius dimension is 0, then the corner will be sharp
+            # (90 degrees). It is also possible to mix tuple values
+            # with numeric
+            Color(*ORANGE)
+            RoundedRectangle(
+                pos=(200, 25),
+                radius=[(40, 20),
+                45.5, 45.5, 0],
+                segments=[2, 3, 3, 1], size=(125, 100))
+
+            Color(*RED)
+            RoundedRectangle(
+                pos=(350, 25),
+                radius=[(40, 40), (40, 40), (20, 20), (20, 20)],
+                segments=[2, 3, 3, 2],
+                size=(150, 100))
+
+
+class DrawRoundedRectanglesApp(App):
+    def build(self):
+        kv = '''
+Widget:
+    canvas:
+        Color:
+            rgba: 1, 1,1, 1
+
+        RoundedRectangle:
+            pos: 575, 400
+            size: 100, 100
+            radius: [0, 50, 0, 50]
+            source: 'kiwi.jpg'
+
+        Color:
+            rgba: 0, 0.8, 0.8, 1
+
+        RoundedRectangle:
+            pos: 575, 275
+            size: 100, 100
+            radius: [(10, 20), (20, 30), (30, 40), (40, 50)]
+
+        RoundedRectangle:
+            pos: 575, 150
+            size: 100, 100
+            radius: [9000]
+            segments: 15
+
+        RoundedRectangle:
+            pos: 550, 25
+            size: 150, 100
+            segments: [1, 2, 1, 3]
+            radius: [30, 40, 30, 40]
+
+'''
+        widget = RoundedRectangleWidget()
+        widget.prepare()
+        kvrect = Builder.load_string(kv)
+        widget.add_widget(kvrect)
+        return widget
+
+
+if __name__ == '__main__':
+    DrawRoundedRectanglesApp().run()

kivy_venv/share/kivy-examples/canvas/scale.py

@@ -0,0 +1,37 @@
+'''
+Scaling Example
+================
+
+This example scales a button using PushMatrix and PopMatrix. It shows
+a static button with the words 'hello world', stretched about its centre by
+a factor of 1.5 horizontally and 5 vertically.
+'''
+
+
+from kivy.app import App
+from kivy.lang import Builder
+
+kv = '''
+FloatLayout:
+
+    Button:
+        text: 'hello world'
+        size_hint: None, None
+        pos_hint: {'center_x': .5, 'center_y': .5}
+        canvas.before:
+            PushMatrix
+            Scale:
+                x: 1.5
+                y: 5
+                origin: self.center
+        canvas.after:
+            PopMatrix
+'''
+
+
+class ScalingApp(App):
+    def build(self):
+        return Builder.load_string(kv)
+
+
+ScalingApp().run()

kivy_venv/share/kivy-examples/canvas/stencil_canvas.py

@@ -0,0 +1,85 @@
+'''
+Stencil demo
+============
+
+This is a test of the stencil graphics instruction inside the stencil view
+widget. When you use a stencil, nothing will be drawn outside the bounding
+box. All the graphics will draw only in the stencil view.
+
+You can "draw" a stencil view by touch & draw. The touch down will set the
+position, and the drag will set the size.
+'''
+
+from kivy.app import App
+from kivy.core.window import Window
+from kivy.graphics import Color, Rectangle
+from kivy.uix.boxlayout import BoxLayout
+from kivy.uix.floatlayout import FloatLayout
+from kivy.uix.button import Button
+from kivy.uix.label import Label
+from kivy.uix.stencilview import StencilView
+from random import random as r
+from functools import partial
+
+
+class StencilTestWidget(StencilView):
+    '''Drag to define stencil area
+    '''
+
+    def on_touch_down(self, touch):
+        self.pos = touch.pos
+        self.size = (1, 1)
+
+    def on_touch_move(self, touch):
+        self.size = (touch.x - touch.ox, touch.y - touch.oy)
+
+
+class StencilCanvasApp(App):
+
+    def add_rects(self, label, wid, count, *largs):
+        label.text = str(int(label.text) + count)
+        with wid.canvas:
+            for x in range(count):
+                Color(r(), 1, 1, mode='hsv')
+                Rectangle(pos=(r() * wid.width + wid.x,
+                               r() * wid.height + wid.y), size=(10, 10))
+
+    def reset_stencil(self, wid, *largs):
+        wid.pos = (0, 0)
+        wid.size = Window.size
+
+    def reset_rects(self, label, wid, *largs):
+        label.text = '0'
+        wid.canvas.clear()
+
+    def build(self):
+        wid = StencilTestWidget(size_hint=(None, None), size=Window.size)
+
+        label = Label(text='0')
+
+        btn_add500 = Button(text='+ 200 rects')
+        btn_add500.bind(on_press=partial(self.add_rects, label, wid, 200))
+
+        btn_reset = Button(text='Reset Rectangles')
+        btn_reset.bind(on_press=partial(self.reset_rects, label, wid))
+
+        btn_stencil = Button(text='Reset Stencil')
+        btn_stencil.bind(on_press=partial(self.reset_stencil, wid))
+
+        layout = BoxLayout(size_hint=(1, None), height=50)
+        layout.add_widget(btn_add500)
+        layout.add_widget(btn_reset)
+        layout.add_widget(btn_stencil)
+        layout.add_widget(label)
+
+        root = BoxLayout(orientation='vertical')
+        rfl = FloatLayout()
+        rfl.add_widget(wid)
+        root.add_widget(rfl)
+        root.add_widget(layout)
+
+        return root
+
+
+if __name__ == '__main__':
+    StencilCanvasApp().run()

kivy_venv/share/kivy-examples/canvas/tesselate.py

@@ -0,0 +1,146 @@
+'''
+Tesselate Demonstration
+=======================
+
+This demonstrates the experimental library for tesselating polygons. You
+should see a hollow square with some buttons below it. You can click and
+drag to create additional shapes, watching the number of vertices and elements
+at the top of the screen. The 'debug' button toggles showing the mesh in
+different colors.
+'''
+
+
+from kivy.app import App
+from kivy.graphics import Mesh, Color
+from kivy.graphics.tesselator import Tesselator, WINDING_ODD, TYPE_POLYGONS
+from kivy.uix.floatlayout import FloatLayout
+from kivy.lang import Builder
+from kivy.logger import Logger
+
+Builder.load_string("""
+<ShapeBuilder>:
+    BoxLayout:
+        size_hint_y: None
+        height: "48dp"
+        spacing: "2dp"
+        padding: "2dp"
+
+        ToggleButton:
+            text: "Debug"
+            id: debug
+            on_release: root.build()
+        Button:
+            text: "New shape"
+            on_release: root.push_shape()
+        Button:
+            text: "Build"
+            on_release: root.build()
+        Button:
+            text: "Reset"
+            on_release: root.reset()
+
+    BoxLayout:
+        size_hint_y: None
+        height: "48dp"
+        top: root.top
+        spacing: "2dp"
+        padding: "2dp"
+        Label:
+            id: status
+            text: "Status"
+""")
+
+
+class ShapeBuilder(FloatLayout):
+    def __init__(self, **kwargs):
+        super(ShapeBuilder, self).__init__(**kwargs)
+        self.shapes = [
+            [100, 100, 300, 100, 300, 300, 100, 300],
+            [150, 150, 250, 150, 250, 250, 150, 250]
+        ]  # the 'hollow square' shape
+        self.shape = []
+        self.build()
+
+    def on_touch_down(self, touch):
+        if super(ShapeBuilder, self).on_touch_down(touch):
+            return True
+        Logger.info('tesselate: on_touch_down (%5.2f, %5.2f)' % touch.pos)
+        self.shape.extend(touch.pos)
+        self.build()
+        return True
+
+    def on_touch_move(self, touch):
+        if super(ShapeBuilder, self).on_touch_move(touch):
+            return True
+        Logger.info('tesselate: on_touch_move (%5.2f, %5.2f)' % touch.pos)
+        self.shape.extend(touch.pos)
+        self.build()
+        return True
+
+    def on_touch_up(self, touch):
+        if super(ShapeBuilder, self).on_touch_up(touch):
+            return True
+        Logger.info('tesselate: on_touch_up (%5.2f, %5.2f)' % touch.pos)
+        self.push_shape()
+        self.build()
+
+    def push_shape(self):
+        self.shapes.append(self.shape)
+        self.shape = []
+
+    def build(self):
+        tess = Tesselator()
+        count = 0
+        for shape in self.shapes:
+            if len(shape) >= 3:
+                tess.add_contour(shape)
+                count += 1
+        if self.shape and len(self.shape) >= 3:
+            tess.add_contour(self.shape)
+            count += 1
+        if not count:
+            return
+        ret = tess.tesselate(WINDING_ODD, TYPE_POLYGONS)
+        Logger.info('tesselate: build: tess.tesselate returns {}'.format(ret))
+        self.canvas.after.clear()
+
+        debug = self.ids.debug.state == "down"
+        if debug:
+            with self.canvas.after:
+                c = 0
+                for vertices, indices in tess.meshes:
+                    Color(c, 1, 1, mode="hsv")
+                    c += 0.3
+                    indices = [0]
+                    for i in range(1, len(vertices) // 4):
+                        if i > 0:
+                            indices.append(i)
+                        indices.append(i)
+                        indices.append(0)
+                        indices.append(i)
+                    indices.pop(-1)
+                    Mesh(vertices=vertices, indices=indices, mode="lines")
+        else:
+            with self.canvas.after:
+                Color(1, 1, 1, 1)
+                for vertices, indices in tess.meshes:
+                    Mesh(vertices=vertices, indices=indices,
+                         mode="triangle_fan")
+
+        self.ids.status.text = "Shapes: {} - Vertex: {} - Elements: {}".format(
+            count, tess.vertex_count, tess.element_count)
+
+    def reset(self):
+        self.shapes = []
+        self.shape = []
+        self.ids.status.text = "Shapes: {} - Vertex: {} - Elements: {}".format(
+            0, 0, 0)
+        self.canvas.after.clear()
+
+
+class TessApp(App):
+    def build(self):
+        return ShapeBuilder()
+
+
+TessApp().run()

kivy_venv/share/kivy-examples/canvas/texture.py

@@ -0,0 +1,143 @@
+'''
+Texture Wrapping and Coordinates Example
+========================================
+
+This example changes texture properties and the properties
+of its containing rectangle. You should see some a multicolored
+texture with sliders to the left and below and buttons at the
+bottom of the screen. The image texture_example_image.png is
+rendered into the rectangle. Sliders change the number of copies of the
+texture (the tex_coords), the size of enclosing rectangle (the taw_height
+and taw_width) while the buttons change how the texture is rendered when more
+than one copy is in the rectangle (the
+texture_wrap).
+
+'''
+
+
+from kivy.uix.widget import Widget
+from kivy.properties import ObjectProperty, ListProperty, StringProperty
+from kivy.lang import Builder
+from kivy.clock import Clock
+from kivy.base import runTouchApp
+
+
+class TextureAccessibleWidget(Widget):
+    texture = ObjectProperty(None)
+    tex_coords = ListProperty([0, 0, 1, 0, 1, 1, 0, 1])
+    texture_wrap = StringProperty('clamp_to_edge')
+
+    def __init__(self, **kwargs):
+        super(TextureAccessibleWidget, self).__init__(**kwargs)
+        Clock.schedule_once(self.texture_init, 0)
+
+    def texture_init(self, *args):
+        self.texture = self.canvas.children[-1].texture
+
+    def on_texture_wrap(self, instance, value):
+        self.texture.wrap = value
+
+
+root = Builder.load_string('''
+<TextureAccessibleWidget>:
+    canvas:
+        Rectangle:
+            pos: self.pos
+            size: self.size
+            source: 'texture_example_image.png'
+            tex_coords: root.tex_coords
+
+<SliderWithValue@BoxLayout>:
+    min: 0.0
+    max: 1.0
+    value: slider.value
+    Slider:
+        id: slider
+        orientation: root.orientation
+        min: root.min
+        max: root.max
+        value: 1.0
+    Label:
+        size_hint: None, None
+        size: min(root.size), min(root.size)
+        text: str(slider.value)[:4]
+
+BoxLayout:
+    orientation: 'vertical'
+    BoxLayout:
+        SliderWithValue:
+            orientation: 'vertical'
+            size_hint_x: None
+            width: dp(40)
+            min: 0
+            max: 5
+            value: 1
+            on_value: taw.tex_coords[5] = self.value
+            on_value: taw.tex_coords[7] = self.value
+        SliderWithValue:
+            orientation: 'vertical'
+            size_hint_x: None
+            width: dp(40)
+            min: 0
+            max: taw_container.height
+            value: 0.5*taw_container.height
+            on_value: taw.height = self.value
+        AnchorLayout:
+            id: taw_container
+            anchor_x: 'left'
+            anchor_y: 'bottom'
+            TextureAccessibleWidget:
+                id: taw
+                size_hint: None, None
+    BoxLayout:
+        size_hint_y: None
+        height: dp(80)
+        BoxLayout:
+            orientation: 'vertical'
+            size_hint_x: None
+            width: dp(80)
+            Label:
+                text: 'size'
+                text_size: self.size
+                halign: 'right'
+                valign: 'middle'
+            Label:
+                text: 'tex_coords'
+                text_size: self.size
+                halign: 'left'
+                valign: 'middle'
+        BoxLayout:
+            orientation: 'vertical'
+            SliderWithValue:
+                min: 0
+                max: taw_container.width
+                value: 0.5*taw_container.width
+                on_value: taw.width = self.value
+            SliderWithValue:
+                min: 0.
+                max: 5.
+                value: 1.
+                on_value: taw.tex_coords[2] = self.value
+                on_value: taw.tex_coords[4] = self.value
+
+    BoxLayout:
+        size_hint_y: None
+        height: dp(50)
+        Label:
+            text: 'texture wrap:'
+            text_size: self.size
+            valign: 'middle'
+            halign: 'center'
+        Button:
+            text: 'clamp_to_edge'
+            on_press: taw.texture_wrap = 'clamp_to_edge'
+        Button:
+            text: 'repeat'
+            on_press: taw.texture_wrap = 'repeat'
+        Button:
+            text: 'mirrored_repeat'
+            on_press: taw.texture_wrap = 'mirrored_repeat'
+''')
+
+
+runTouchApp(root)
